AXIS 2020 Surf Foil Front Wing (S-Series)
Axis
$941.00
or 6 weekly payments from $156.83 learn more
Carbon construction. 2019 graphics on the wings give you all possible measurements so you can properly compare with other wings and foils and quickly swap to other sizes as needed.
SIZES: 102cm | 92cm | 82cm | 75cm | 68cm
1020mm Wing Technical Data
- CHORD: 250cm
- ACTUAL AREA: 2051 square cm / 318 square inches
- SPAN: 102 cm / 40 inches
- PROJECTED AREA: 2013 square cm / 312 square inches
- VOLUME: 4161 cubic cm / 254 cubic inches
920mm Wing Technical Data
- CHORD: 250cm
- ACTUAL AREA: 1852 square cm / 287 square inches
- SPAN: 92 cm / 36 inches
- PROJECTED AREA: 1816 square cm / 281 square inches
- VOLUME: 3753 cubic cm / 229 cubic inches
820mm Wing Technical Data
- CHORD: 222.7mm
- ACTUAL AREA: 1528 square cm / 236 square inches
- SPAN: 82 cm / 32 inches
- PROJECTED AREA: 1443 square cm / 223 square inches
- VOLUME: 2657 cubic cm / 162 cubic inches
750mm Wing Technical Data
- CHORD: 220mm
- ACTUAL AREA: 1359 square cm / 211 square inches
- SPAN: 75 cm / 29.5 inches
- PROJECTED AREA: 1272 square cm / 197 square inches
- VOLUME: 2360 cubic cm / 144 cubic inches
680mm Wing Technical Data
- CHORD: 200mm
- ACTUAL AREA: 1120 square cm / 174 square inches
- SPAN: 68 cm / 26.77 inches
- PROJECTED AREA: 1048 square cm / 162 square inches
- VOLUME: 1765 cubic cm / 108 cubic inches
