ARMSTRONG 2020 'Create Your Own' High Speed Foil Complete

Armstrong

$2,849.00

or 6 weekly payments from $474.83 Group Created with Sketch. learn more

Front Wing
Fuselage
Mast

Armstrong foils represent the top of the market in terms of quality and performance. Here you can create your own dream setup, tailored perfectly to your needs!


The High Speed Foil Kit is super responsive and stable. No sales pitch is necessary with this Foil kit. Buy it, you'll love it.


The package includes everything you'll need to get ripping! (apart from the board!):

  • Front wing (size of your choice - see information below)
  • Tail wing (one size) & Tail Trim
  • Mast (size of your choice - see information below)
  • Fuselage (size of your choice - see information below)
  • Carry Bag
  • Bolt set & tools (complete)


BONUS OFFER: GET 10% OFF ANY ADDITIONAL FRONT WING WITH YOUR PACKAGE PURCHASE. CONTACT US TO ARRANGE.


NOTE: For individual Foil Components purchase: see tab "FOIL COMPONENTS"


FRONT WINGS:


Front Wing Options:

  • HS1050cm2
  • HS1550cm2
  • HS1850cm2


The main wings are shaped for maximum stability and predictability at all speeds. The foil sections have been carefully designed by one of the world’s foremost sport wing designers.


Continuous testing and refinement helped Armstrong find a combination of planform, leading and trailing edge sweep and the right amount of anhedral curve that delivers super smooth flow, giving a more connected surf like feeling while on the fly.


Construction is based around a high-density foam core, which is encapsulated in Aramid cloth before being wrapped with 100% High Modulus Carbon.


HS1050 Front Wing

The High Speed 1050 wing is a true performance surf wing.  Fast, stable, responsive, agile and with great glide make it the perfect choice for carving turns and shredding waves.


Developed form the ultra-successful CF1200, the HS1050 is the logical step for progressive riders wanting to take it to the next level, it's also the perfect partner to the HS1550.
Ideal for medium wave riding, Wing SUP, Windsurfing or wake foiling.


The main wings are shaped for maximum stability and predictability at all speeds.
The foil sections have been carefully designed by one of the world’s foremost sport wing designers.


Continuous testing and refinement helped us find a combination of planform, leading and trailing edge sweep and the right amount of anhedral curve that delivers super smooth flow, giving a more connected surf like feeling while on the fly.


Construction is based around a high-density foam core, which is encapsulated in Aramid cloth before being wrapped with 100% High Modulus Carbon.


HS1550 Front Wing

The new HS(High Speed) wing line is designed for the right balance of speed, turning, pumping, and low speed lift. Like all Armstrong foils, this kit is super easy to ride and ridiculously stable.


Armie Armstrong got fed up with all of the foils he was buying breaking, seizing together and not working like he wanted them to, so he put together an all-star team and Armstrong Foils were born. These are top quality foils with unique performance characteristics that make the foils really easy to learn with yet all the top pros are frothing to get their hands on them.


HS1850 Front Wing

The super sleek High Speed 1850 is the largest performance surf wing in our HS range. It’s fast, stable, has fantastic glide and has incredible response for its size! Perfect for carving turns or shredding up smaller waves then pumping back out for more. For Wing Foiling the HS1850 is perfectly suited, it has amazing range, taking experienced riders from sub 10 knot riding, all the way to 25 knots!


Developed from the ultra-successful HS1050 and HS1550, the HS1850 is the logical step for progressive riders wanting to access the next level.


MAST LENGTHS


Length Options:

  • 45cm - Easiest for learning all foil sports. Most stable. Contact us for availability.
  • 60cm - Shallow water and reef foiling where hitting the bottom might be an issue. Also a good choice for easy learning all foil sports. Contact us for availability.
  • 72cm - The go to Foil Surf mast. An easy all rounder for all foil sports
  • 85cm - The 'do everything mast' : Intermediate/Advanced. SUP, Downwind, Kite, Wake, and Tow in Surfing
  • 100cm - This is the choice for experienced Kite, Tow in Surfing and big wave charging.


There is no golden rule to chose your mast length. It is key to understand that the longer the mast length the more difficult it is to maintain stability, and the more extreme your wipeouts will be. It is our recommendation that whatever your sport, you start on a short or medium mast length i.e. 75cm.


In surfing, longer mast lengths are designed to allow extra pumping room and allow more maneuverability through turns. Whereas for kiting, a longer mast length will allow a greater upwind angle without the wing coming out of the water (advanced riding). It will also allow the kiter to maintain a steady heading through larger ocean chop / waves.


ASSAULT 'SHORT MAST' OFFER: With all complete foil purchases, we offer a 'short' mast loan service for FREE. This allows you to jump start your learning process. Its super simple to swap back your mast for your long term option once you have acquired the basic skills. Contact us to arrange.


FUSELAGE

The shorter the fuselage the less stable the foil becomes and turns become faster and tighter. The fuselage options are:

  • T50cm - Shortest fuselage for the absolute tightest turns and greatest manoeuvrability. Recommended for advanced riders.
  • T60cm - Shorter fuselage for more intermediate riders to get the most out of their turns. Less stable than the 70cm fuselage.
  • T70cm - Very stable fuselage, & the most popular fuselage length in our range for the all round rider.
  • T80cm - The most stable length which is great for windsurfing or downwind-ing.


TAIL WING


HS 232 - 2 in 1 Tail Wing: Our freshly minted and innovative High Speed 232 (212 Chop Shop) Tail Wing is a complete performance upgrade for ALL Armstrong foils. The reduced area and drag make it ideal for higher speed and tighter turning.


Developed hand in hand with the Armstrong HS front wings the 232 helps generate more acceleration and whip so you can be in the right place to rip.


The HS 232 is also compatible with the entire CF foil range and is the perfect upgrade delivering more agility and speed. Ideal for experienced riders of all foil sports.


In addition, our futuristic layup has been re-engineered so the ultra frothers out there are free to Chop Shop the tips into an HS 212cm2 - without structural issues.


The unique flow fences flow improve stability by minimize the disruption from turbulent flow off the front wing, mast and fuselage.


The tail wing has a foam core wrapped in Hexi-Core Mat, covered in the highest quality Carbon keeping it light and super rigid.

Titanium screw inserts in keeping with our philosophy of zero corrosion materials throughout the entire product.


TITANIUM TRIM FAITINGS (TTF)


TTF (Titanium Trim Fairings) - State of the art rear wing configuration incorporates easy to change, honeycomb Titanium Trim Fairings that allow you to fine tune the UNI Tail Wing to your personal feeling.


The Titanium trim fairings set the angle of attack of the tail wing. We use -2 degree, Zero degree and +1 degree trim options. These adjustments work in conjunction with changing the front wings, fueslarge length and required use:

  • -2 Degree: For learning, larger boards/people and windsurf freeride. Tail has more downforce giving front wing more lift at lower speeds and better Yaw (directional) stability.
  • 0 Degree: is best with the CF800 wing at higher speeds kiting or tow surfing and good all around with the CF1200 and CF1600 wings.
  • +1 Degree: For more top end speed control on all wings and better pump for advanced riders looking to maximise glide and to Down Wind Foil. During a drop or speed spike the +1 helps keep the wing in the water and adds control during turns.


In the notes please state which degree TTF you would like.





Note: Please allow additional delivery time with these products, as they are specialist.




Advice: Our team are passionate, experienced boardriders. We have a wealth of knowledge and expertise to share and we encourage you to ask for our advice and guidance.


Delivery: We offer discounted shipping to New Zealand (North and South Island). Quotes provided at checkout.


Returns: Our mission is to ensure you are supplied with products that are suitable for their intended purpose. We will always do our best to accommodate genuine returns / exchanges, please see our Terms and Conditions for more information.



SKU: 30277 TAGS: Foiling | Kite, Foiling | SUP, Foiling | Surf, Foiling | Tow / Wake, Foiling | Wing
