ARMSTRONG 2020 SUP / Wing Multi Wing Kit CF2400 & CF1600

Armstrong

$3,827.00

or 6 weekly payments from $637.83 Group Created with Sketch. learn more

Front Wing
Fuselage
Mast

Armstrong foils represent the top of the market in terms of quality and performance. This foil kite is aimed to kickstart the beginning process in learning to SUP and Wing Foil.


The package includes everything you'll need to get ripping! (apart from the board!):

  • Front wings: CF2400 & CF1600. Multi Wing Deal Includes 10% off Extra Wing.
  • Uni Tail wing (one size) & Tail Trim
  • Mast: 72cm
  • Fuselage: 70cm
  • Covers & Carry Bag
  • Bolt set & tools (complete)


NOTE: For individual Foil Components purchase: see tab "FOIL COMPONENTS" on home page


FRONT WINGS:

  • CF1600cm2
  • CF2400cm2


The main wings are shaped for maximum stability and predictability at all speeds. The foil sections have been carefully designed by one of the world’s foremost sport wing designers.


Continuous testing and refinement helped Armstrong find a combination of planform, leading and trailing edge sweep and the right amount of anhedral curve that delivers super smooth flow, giving a more connected surf like feeling while on the fly.


Construction is based around a high-density foam core, which is encapsulated in Aramid cloth before being wrapped with 100% High Modulus Carbon.


1600 Front Wing

The Carving Freeride 1600 is the go to foil for smaller wave riding, down wind swell riding, SUP and wake surf. Although perfectly suited forbeginners of all foil disciplines the CF1600 is the multi tool of the foil world. When the CF1600 is setup in combo with the stiff mast/fuselage, it's a stable and easy carving foil.


The CF1600 is designed to get you up and flying on the foil easily at low speed. This high lift front wing produces smooth progressive lift at low speeds, together with the new generation wingtips making it easier to control as the foil starts to fly and accelerate.


Wing Dimensions

  • Wing area: 1600cm2  (248in2)
  • Wing span: 780mm
  • Weight: 1600g


Suitable for:

  • Surf / SUP: Ideal surf wing for small / medium waves
  • Kiteboarding: Ultra light wind / low speed riding.
  • Wake: Versatile towing and wake foiling (heavier rider range).
  • Windsurf: Medium / heavy riders or lightwind use.
  • Wing: Great all round wing for wing foiling in all conditions.


2400 Front Wing

The 2400 V2 is shaped for maximum stability and predictability at slower speeds.
The foil section have been carefully designed for stability, by one of the world’s foremost sport wing designers.


Continuous testing and refinement helped us find a combination of planform, leading and trailing edge sweep and the right amount of anhedral curve that delivers super smooth flow, giving a more connected surf like feeling while on the fly.


Construction is based around a high-density foam core which is encapsulated in Aramid cloth before being wrapped with 100% High Modulus Carbon.


Wing Dimensions

  • Wing area: 2390cm2 (370 in2)
  • Wing span: 970mm
  • Weight: 1800g


Suitable for:

  • Surf / SUP: Ideal surf wing for small / tiny waves.
  • Wake: Versatile towing and wake foiling (heavier rider range).
  • Wing: Low wind / small wings


MAST - 72cm

Our new V2 fully tapered one piece masts are ultra solid at the top and slick through the water down below. The unique quad c beam core layup delivers a mast with smooth consistent reactive flex, generating sweet handling response and better stability by smoothing out bumps and flexing precisely to drive you through turns.


The V2 masts also feature bombproof zero corrosion Bi Directional Titanium Washer and Titanium T Nut system, which creates a rock solid connection between mast and board.
The V2 mast construction and shape combine to make a mast that will deliver predictably every time.


72cm /28.5" is the go to Foil Surf mast. An easy all rounder for all foil sports.


ASSAULT 'SHORT MAST' OFFER: With all complete foil purchases, we offer a 'short' mast loan service for FREE. This allows you to jump start your learning process. Its super simple to swap back your mast for your long term option once you have acquired the basic skills. Contact us to arrange.


FUSELAGE

The TC70 is our most popular fuselage length in our range for the all round rider. The longer length gives more overall stability and provides a more powerful pumping action.


The Armstrong HEX Fuselage is a ground breaking work of art in terms of engineering and design.


The fuselage has a solid Titanium core running throughout its length. The core is then shrouded in 5mm solid wall Carbon tube.The multi wing HEX fitting for the mast and front wing gives 360 degree surface contact, maximising the load distributing area.


This unique fuselage construction easily handles the highly leveraged opposing flex loads as the mast and wings are directly keyed into the Titanium core, taking your ride to the next level.


Weight: 425g


TAIL WING


The Uni Tail Wing is the perfect all rounder for all foil sports. It incorporates the perfect amount of anhedral shape in the center and dihedral at the tips to allow smooth but precise pitch control at all speeds and bank angles.


The unique flow fences flow improve stability by minimize the disruption from turbulent flow off the front wing, mast and fuselage.


The tail wing has a foam core wrapped in Hexi-Core Mat, covered in the highest quality Carbon keeping it light and super rigid.


Titanium screw inserts in keeping with our philosophy of zero corrosion materials throughout the entire product.


Specifications:

  • Wing area: 300cm2 (46in2)
  • Weight: 220g


TITANIUM TRIM FAIRINGS (TTF)


TTF (Titanium Trim Fairings) - State of the art rear wing configuration incorporates easy to change, honeycomb Titanium Trim Fairings that allow you to fine tune the UNI Tail Wing to your personal feeling.


The Titanium trim fairings set the angle of attack of the tail wing. We use -2 degree, Zero degree and +1 degree trim options. These adjustments work in conjunction with changing the front wings, fueslarge length and required use:

  • -2 Degree: For learning, larger boards/people and windsurf freeride. Tail has more downforce giving front wing more lift at lower speeds and better Yaw (directional) stability.
  • 0 Degree: is best with the CF800 wing at higher speeds kiting or tow surfing and good all around with the CF1200 and CF1600 wings.
  • +1 Degree: For more top end speed control on all wings and better pump for advanced riders looking to maximise glide and to Down Wind Foil. During a drop or speed spike the +1 helps keep the wing in the water and adds control during turns.


In the notes please state which degree TTF you would like.




Note: Please allow additional delivery time with these products, as they are specialist.




Advice: Our team are passionate, experienced boardriders. We have a wealth of knowledge and expertise to share and we encourage you to ask for our advice and guidance.


Delivery: We offer discounted shipping to New Zealand (North and South Island). Quotes provided at checkout.


Returns: Our mission is to ensure you are supplied with products that are suitable for their intended purpose. We will always do our best to accommodate genuine returns / exchanges, please see our Terms and Conditions for more information.



SKU: 30335 TAGS: Foiling | SUP, Foiling | Wing
