F-ONE 2021/22 'Create Your Own' Gravity Carbon Foil Complete
or 6 weekly payments from $426.33 learn more
NOTE: ALL OF OUR COMPLETE F-ONE FOIL PACKAGE PRICES INCLUDE A 10% PACKAGE DISCOUNT.
BONUS: GET 10% OFF ANY ADDITIONAL FRONT WING WITH YOUR PACKAGE PURCHASE. CONTACT US TO ARRANGE.
The GRAVITY CARBON foils are very easy and stable to learn on and progress with. They are designed to provide a solid lift with a progressive take-off, and are of great use for any rider in light and small conditions.
Built using the Monobloc structure with pre-preg carbon, the foils are both very light and strong. This setup brings improved load transmission and better stiffness throughout the different parts for maximum control. The TITAN connection allows to plug in either an aluminum or carbon mast, and the fuselage is split in two to facilitate transport.
- 100% - Take Off
- 70% - Speed
- 90% - Carving
- 75% - Pumping
This package includes everything you'll need to get ripping! (apart from the board!):
- Front wing (size of your choice - see information below)
- Tail wing (Stab C275 Surf - see information below)
- Mast (size of your choice - see information below)
- Fuselage ('Long' provided by default - contact us regarding other options)
- Mast Foot
- Base plate (contact us for tuttle option)
- Bolt set & tools (complete)
The range now includes two sizes: 1800 and 2200 cm². Foils with such areas support an early take-off and more lift and stability. However, we still made sure they also come with enough aspect ratio to maintain a decent speed range and to avoid unnecessary drag. Their massive span allows you to control low speeds, and these foils also turn and carve well.
- Aspect Ratio: 5.0
- Accessible and straightforward foil
- Smooth and early take-off
- Stability, speed control, and lift
- Reliable and efficient in light conditions
- Gravity 1800 - ideal to enjoy the smallest waves, venture on downwinders.
- Gravity 2200 - ideal for riders >80kg or using boards >7’0. It is designed to surf the smallest waves, and venture on downwinders.
The tail component of the gravity fuselage (the front component is part of the front wing). This component is included as part of the Gravity Foil Complete setup.
- Long (41 cm): offers more stability and a more efficient pumping – recommended with Gravity 1800/2200
Contact us if you would like a different fuselage tail than recommended.
REAR WING - STAB C275 SURF
Both GRAVITY CARBON are recommended with the C275 SURF stab. Progressive and versatile, this stab will bring stability, control, and confidence to your ride.
Built in Carbon Composite and designed to be securely mounted on F-ONE fuselages, its profile and angle of incidence were tuned to achieve a very intuitive balance which will help you get your foiling maneuvers in more easily.
- Early lift and great stability
- Perfect control at all time
Contact us if you would like a different fuselage tail than recommended (e.g. Stab C250 Surf)
MAST (ALU MASTS)
The F-ONE aluminium mast can be used for all disciplines, kite, surf, stand up paddle and windsurf. The profile is extruded with precision from 6063 aluminium block. The shape of its section benefits from our years of experience in kitefoiling to provide the best gliding feel while keeping the strength up and the weight down. It comes with two stainless steel helicoil inserts at the bottom and at the top to fasten the connecting parts and is therefore fully modular.
The aluminium mast can be used on every foil of the range and it is very easy to jump from one length to another. A number of parts are available for board connection (Plate, KF, Deep KF, Tuttle).
SIZES: 45cm, 55cm, 65cm, 75cm, 85cm, 95cm
Titan Connection: the wing connects directly to the mast via the Titan mast foot and the fuselage is split in two parts in order to simplify transportation. This setup offers better load transmission and better stiffness throughout the different parts for maximum control.
MAST (HM CARBON)
New for 2021! A true masterpiece of composite craftmanship and design, the F-ONE Carbon Mast was designed to transform your foiling experience by a significant improvement of the glide and a dramatic weight reduction matched with impressive rigidity.
The design target was to enhance the thrills of foiling, and we believe foiling is always better when your foil glides better, when your foil is easier to drive and when it reacts better to your demands, even at the highest speeds. This is what you will experience when using the F-ONE carbon mast on your existing F-ONE foil or on a new one.
Available in 75 cm, 85 cm and 105 cm, the F-ONE Carbon Mast is ready for all disciplines: surf, wing, kite, SUP. It features a 4-bolt plate at the top (hole spacing: 160×90mm) and an integrated Titan mast foot at the bottom. It can be connected to virtually all boards on the market featuring the twin track system and can receive all the wings and fuselage that feature the TITAN connection slot.
All components are molded together or bonded in factory to ensure the best rigidity throughout. The mast, therefore, comes as a one-piece object, built-in carbon pre-preg with a hollow structure which is molded and cured in one-shot. The numerous layers of carbon are laminated one by one to our exacting demands regarding fiber weight and orientation to achieve the rigidity needed, both in bending and torsion, to keep full control in all situations and at high speeds.
A carbon mast is a superior bit of kit. We think it needs to look great and deliver a superior and flawless behavior on the water. This is what we’ve achieved with the F-ONE Carbon Mast.
SIZES: 75cm, 85cm, 95cm, 105cm
