F-ONE 2020 'Create Your Own' Mirage Kite Foil Complete

F-One

$2,385.00

or 6 weekly payments from $397.50 Group Created with Sketch. learn more

Front Wing
Mast

Introducing the F-One 2020 gravity foil range. Built with pre-preg carbon for the best weight to strength ratio, with a super light core.Titan Connection: the wing connects directly to the mast via the Titan mast foot and the fuselage is split in two parts in order to simplify transportation. This setup offers better load transmission and better stiffness throughout the different parts for maximum control.


This package includes everything you'll need to get ripping! (apart from the board!):

  • Front wing (size of your choice - see information below)
  • Tail wing (one size).
  • Mast (size of your choice - see information below)
  • Fuselage
  • Mast Foot
  • Base plate (contact us for tuttle option)
  • Bolt set & tools (complete)


NOTE: For individual Foil Components purchase: see tab "FOIL COMPONENTS" on home page


FRONT WINGS:

Flatter in the middle with tips accurately arched down the three wings share a similar arch profile which provides plenty of control and total maneuverability. Their aspect ratio is compact, providing more freedom in all maneuvers. They also have a refined twist distribution which not only helps with the glide but also make the power of the wing more manageable when carving lines.


To maintain optimal control, we build these wings in carbon pre-preg. And the larger sizes also have a foam core to keep them light. All sizes share the same metal insert with the FCD connector fully machined via CNC for a strong and perfect assembly.


The MIRAGE wings fit all 2018 F-ONE foils, and also previous versions. All perfectly balanced, the MIRAGE wings are very accessible to any skill level with the larger sizes and will impress the most advanced riders with the smaller sizes.


They are perfect for anyone who likes to cruise and carve some lines on their foil.


Front Wing Options:

  • 650 cm2 – the smallest size also has the thinnest profile to provide a really nice glide together with some endless carving possibilities. The best speed to carving combo.
  • 800 cm2 – the most versatile size of the range offers good lift, good glide and super smooth manoeuvrability.
  • 1 000 cm2 – the largest model offers absolute speed control, early lift and is great at low speed transitions. Can also be used on Surf or SUP foils when riding regular waves


FUSELAGE - Titan 60

The TITAN fuselage 60 is a fuselage that connectes to F-ONE aluminium or carbon masts via a TITAN connection. It is made of aluminium 6061, CNC machined with high precision and fully anodized. The TITAN fuselage 60 must be fasten to the mast or mast foot using three M6x25mm tapered head screws.


At the forward end, this fuselage can accept all wings of any size with FCD connectors. Once it is plugged in, the front wing must be fastened with 210mm main rod. A stabilizer can be fastened at the back using two M6x16mm tapered head screws . The craddle for the stabilizer was designed to keep the foil in trim when using F-ONE stabilizers.


Length : 60cm
Weight : 0.61 kg


REAR WING - StabC300

Versatile and progressive, the C300 stabilizer can be combined with any front wings and fits a very large range of practices. Equipped with generous winglets, the stabilizer blade offers fantastic control with enough surface area to provide full confidence in all situations.Built in Carbon Composite and designed to be securely mounted on F-ONE fuselages, its profile and angle of incidence were tuned to achieve a very intuitive balance which will help you get your foiling maneuvers in more easily.


OVERVIEW:

  • Early lift and great stability
  • Perfect control at all time
  • Works for Kite, SUP, and Wind Foiling!


MAST

The F-ONE aluminium mast can be used for all disciplines, kite, surf, stand up paddle and windsurf. The profile is extruded with precision from 6063 aluminium block. The shape of its section benefits from our years of experience in kitefoiling to provide the best gliding feel while keeping the strength up and the weight down. It comes with two stainless steel helicoil inserts at the bottom and at the top to fasten the connecting parts and is therefore fully modular.


The aluminium mast can be used on every foil of the range and it is very easy to jump from one length to another.  A number of parts are available for board connection (Plate, KF, Deep KF, Tuttle).


SIZES: 45cm, 55cm, 65cm, 75cm, 85cm, 95cm








Advice: Our team are passionate, experienced boardriders. We have a wealth of knowledge and expertise to share and we encourage you to ask for our advice and guidance.


Delivery: We offer discounted shipping to New Zealand (North and South Island). Quotes provided at checkout.


Returns: Our mission is to ensure you are supplied with products that are suitable for their intended purpose. We will always do our best to accommodate genuine returns / exchanges, please see our Terms and Conditions for more information.



SKU: 30279 TAG: Foiling | Kite
