NAISH 2020 'Create Your Own' Jet Foil Complete

Naish

$1,849.00

or 6 weekly payments from $308.17 Group Created with Sketch. learn more

Front Wing
Mast Length

Bridging the gap for all foiling disciplines, the Freemove Foil offers a multitude of new features and sets a new performance standard across disciplines. This is the perfect foil package for kiters who want great lightwind performance with a more playful ride while still offering versatility that reaches towards surf, SUP, wake and even windsurf foiling.


For 2020, Naish introduces an entirely new line of surf foils—reimagined, redesigned, and fine-tuned over months of testing to improve performance on every level. Further developing our delta wing concept, we’ve focused on better pumping and improving our already excellent agility. The new wings feature new proprietary foil sections that deliver more lift while reducing drag, smoothed frontal geometry that makes turning more intuitive while maintaining the ‘surf’ feel that makes our wings so popular, and refined wingtips that provide excellent grip during turns and are also safer. These new wings are matched by new stabilizers (back wings) that connect seamlessly to our new fuselage design, and deliver improved performance across the board.


This Package Includes:

  • Jet Front Wing (Choose your size - see details below)
  • Rear Wing (Stabilizer 320, 450 or H/A 310)
  • Surf Fuselage (one size)
  • Mast (choose your length)
  • Abracadabra Plate adaptor
  • Titanium Foil Assembly Screw Set
  • Mounting Screw Set
  • Tool


NOTE: For individual Foil Components purchase: see tab "FOIL COMPONENTS"


FRONT WINGS


Jet 1050 Wing

  • Aspect Ratio: 4.0
  • Wingspan: 25.2"/64 cm
  • Projected Surface Area:162.8 in²/1050 cm
  • Comes with 320 Stabilizer as standard (contact us to swap)




Jet 1250 Wing

  • Aspect Ratio - 4.0
  • Wingspan - 27.6"/70 cm
  • Projected Surface Area - 193.8 in²/1250 cm²
  • Comes with 450 Stabilizer as standard (contact us to swap)


Jet 1650 Front Wing

  • Aspect Ratio - 4.8
  • Wingspan - 34.8"/88.5 cm
  • Projected Surface Area - 255.8 in²/1650 cm²
  • Comes with 450 Stabilizer as standard (contact us to swap)


Jet High Aspect 1800 Front Wing

  • Aspect Ratio - 5.6
  • Wingspan - 39.4"/100 cm
  • Projected Surface Area - 279 in²/1800cm²
  • Comes with High Aspect 310 Stabilizer as standard (contact us to swap)


Jet 2000 Front Wing

  • Aspect Ratio - 5.1
  • Wingspan - 39.4"/100 cm
  • Projected Surface Area - 310 in²/2000 cm²
  • Comes with 450 Stabilizer as standard (contact us to swap)


Jet 2450 Front Wing

  • Aspect Ratio - 4.1
  • Wingspan - 39.4"/100 cm
  • Projected Surface Area - 380 in²/2450 cm²
  • Comes with 450 Stabilizer as standard (contact us to swap)






MAST


As the sport of foiling progresses so do our components. Four new sizes are introduced for 2020 that can be used in any sport. Focusing on performance, our masts are aircraft grade extruded aluminum that are 120 grit sandblasted before anodizing. After anodizing all masts are wet sanded using 600 grit to achieve the best possible surface structure and create an ultra smooth and clean release when foiling. Masts connect to both the board mount and fuselage with three M6 x 30 mm titanium Torx screws at each end. Titanium has advantages in weight and are less susceptible to corrosion. All masts are available as separate accessories without screws, available separately, to accommodate different skill levels and sports.


FEATURES:

  • Aluminum = Stiffness + corrosion resistance + low weight
  • Interchangeable Board Mounts =Added versatility


REAR WING / STABILIZER:


All new for 2020, the 320 backwing adds stability to the excellent turning ability of our previous anhedral design, increasing performance on all levels – speed, control, and even more intuitive turning. By moving the rudder control function to the wingtips, we’ve reduced drag and freed up more center span for stability.


320 SPECIFICATION

  • Projected Surface Area: 49.6 in2 / 320 cm2
  • Wingspan:  16.4'' / 42cm
  • Aspect Ratio: 5.6
  • Performance: Med/High lift / low drag
  • Comes with 1050 Front Wing


450 SPECIFICATION:

  • Projected Surface Area: 69.3 in2 / 450 cm2
  • Wingspan:  20.1'' / 51cm
  • Aspect Ratio: 5.8
  • Performance: High lift / low drag
  • Comes with >1250 Front Wings


FUSELAGE:


For 2020, the Naish modular fuselage system has been completely redesigned – a new external geometry reduces weight and hydrodynamic drag, and a new simplified rear wing connection makes assembly a breeze. The industry standard indexed scarf front wing connection has been retained so that existing and future wing designs are interchangeable. Naish fuselages are CNC precision cut from aircraft grade aluminum, and then 120 grit sandblasted pre anodizing for optimum smoothness and durability.



Note: Please allow additional delivery time with these products, as they are specialist.




Advice: Our team are passionate, experienced boardriders. We have a wealth of knowledge and expertise to share and we encourage you to ask for our advice and guidance.


Delivery: We offer discounted shipping to New Zealand (North and South Island). Quotes provided at checkout.


Returns: Our mission is to ensure you are supplied with products that are suitable for their intended purpose. We will always do our best to accommodate genuine returns / exchanges, please see our Terms and Conditions for more information.



SKU: 30280 TAGS: Foiling | Kite, Foiling | SUP, Foiling | Surf, Foiling | Tow / Wake, Foiling | Wing
