ARMSTRONG 2020 Kite / Tow / Surf Multi Wing Kit CF1200 & CF800

Armstrong

$3,708.00

or 6 weekly payments from $618.00 Group Created with Sketch. learn more

Out of stock

Armstrong foils represent the top of the market in terms of quality and performance. This foil kite is aimed to kickstart the beginning process in learning to SUP and Wing Foil.


The package includes everything you'll need to get ripping! (apart from the board!):

  • Front wings: CF1200 & CF800. Multi Wing Deal Includes 10% off Extra Wing.
  • Uni Tail wing 300 & Tail Trim (TTF 0 degree & +1 degree)
  • Mast: 85cm
  • Fuselage: 60cm
  • Covers & Carry Bag
  • Bolt set & tools (complete)


NOTE: For individual Foil Components purchase: see tab "FOIL COMPONENTS" on home page


FRONT WINGS:

  • CF800cm2
  • CF1200cm2


The main wings are shaped for maximum stability and predictability at all speeds. The foil sections have been carefully designed by one of the world’s foremost sport wing designers.


Continuous testing and refinement helped Armstrong find a combination of planform, leading and trailing edge sweep and the right amount of anhedral curve that delivers super smooth flow, giving a more connected surf like feeling while on the fly.


Construction is based around a high-density foam core, which is encapsulated in Aramid cloth before being wrapped with 100% High Modulus Carbon.


CF800 Front Wing


The Carving Freeride 800 with its inflected tips is ultra smooth to ride. It's inspiring stability allows you to really carve with confidence. The deep anhedral through the centre helps prevent the foil ventilating during steep carving turns and gives great feedback.


DIMENSIONS:

  • Wing area: 800cm2 (124in2)
  • Wingspan: 600mm
  • Weight: 730g


CF1200 Front Wing


The Carving Freeride 1200 wing is all about taking your surf foiling to the next level. Extremely stable yet rips turns rail to rail like a dream and pumps to connect when required. If you want to surf foil then look no further.


DIMENSIONS:

  • Wing area: 1200cm2 (186in2)
  • Wingspan: 675mm
  • Weight: 995g


MAST - 85cm

Our new V2 fully tapered one piece masts are ultra solid at the top and slick through the water down below. The unique quad c beam core layup delivers a mast with smooth consistent reactive flex, generating sweet handling response and better stability by smoothing out bumps and flexing precisely to drive you through turns.


The V2 masts also feature bombproof zero corrosion Bi Directional Titanium Washer and Titanium T Nut system, which creates a rock solid connection between mast and board.
The V2 mast construction and shape combine to make a mast that will deliver predictably every time.


85cm - The 'do everything mast' : Intermediate/Advanced. SUP, Downwind, Kite, Wake, and Tow in Surfing


ASSAULT 'SHORT MAST' OFFER: With all complete foil purchases, we offer a 'short' mast loan service for FREE. This allows you to jump start your learning process. Its super simple to swap back your mast for your long term option once you have acquired the basic skills. Contact us to arrange.


FUSELAGE - 60cm


The TC60 allows greater maneuverability and is suited to the accomplished rider. The shorter length offers wave riders tighter carving turns and quicker response for shredding waves.


The Armstrong HEX Fuselage is a ground breaking work of art in terms of engineering and design.


The fuselage has a solid Titanium core running throughout its length. The core is then shrouded in 5mm solid wall Carbon tube.The multi wing HEX fitting for the mast and front wing gives 360 degree surface contact, maximising the load distributing area.


This unique fuselage construction easily handles the highly leveraged opposing flex loads as the mast and wings are directly keyed into the Titanium core, taking your ride to the next level.


Weight: 425g


TAIL WING - Uni 300


The Uni Tail Wing is the perfect all rounder for all foil sports. It incorporates the perfect amount of anhedral shape in the center and dihedral at the tips to allow smooth but precise pitch control at all speeds and bank angles.


The unique flow fences flow improve stability by minimize the disruption from turbulent flow off the front wing, mast and fuselage.


The tail wing has a foam core wrapped in Hexi-Core Mat, covered in the highest quality Carbon keeping it light and super rigid.


Titanium screw inserts in keeping with our philosophy of zero corrosion materials throughout the entire product.


Specifications:

  • Wing area: 300cm2 (46in2)
  • Weight: 220g


TITANIUM TRIM FAIRINGS (TTF)


TTF (Titanium Trim Fairings) - State of the art rear wing configuration incorporates easy to change, honeycomb Titanium Trim Fairings that allow you to fine tune the UNI Tail Wing to your personal feeling.


The Titanium trim fairings set the angle of attack of the tail wing. We use -2 degree, Zero degree and +1 degree trim options. These adjustments work in conjunction with changing the front wings, fueslarge length and required use:

  • -2 Degree: For learning, larger boards/people and windsurf freeride. Tail has more downforce giving front wing more lift at lower speeds and better Yaw (directional) stability.
  • 0 Degree: is best with the CF800 wing at higher speeds kiting or tow surfing and good all around with the CF1200 and CF1600 wings.
  • +1 Degree: For more top end speed control on all wings and better pump for advanced riders looking to maximise glide and to Down Wind Foil. During a drop or speed spike the +1 helps keep the wing in the water and adds control during turns.


Note: Included with all complete foils are TTF 0 degree and TTF +1 degree (see notes below). Contact us for alternate options.




Note: Please allow additional delivery time with these products, as they are specialist.




Advice: Our team are passionate, experienced boardriders. We have a wealth of knowledge and expertise to share and we encourage you to ask for our advice and guidance.


Delivery: We offer discounted shipping to New Zealand (North and South Island). Quotes provided at checkout.


Returns: Our mission is to ensure you are supplied with products that are suitable for their intended purpose. We will always do our best to accommodate genuine returns / exchanges, please see our Terms and Conditions for more information.



SKU: 30333 TAGS: Foiling | Tow / Wake, Foiling | Kite, Foiling | Surf
