F-ONE 2021 'Create Your Own' Mirage Kite Foil Complete

F-One

$1,778.00

or 6 weekly payments from $296.33 Group Created with Sketch. learn more

Out of stock

Fun, designed for carving and really versatile, the Mirage foils will transform your kitefoiling experience.

  • Great Carving
  • Rail to Rail Surf Feeling
  • Huge speed range
  • Monobloc Carbon Construction
  • Easier than ever


This package includes everything you'll need to get ripping! (apart from the board!):

  • Front wing (size of your choice - see information below)
  • Carbon Fuselage Tail (one size).
  • Tail Wing (comes with StabC300 Stabiliser - contact us for more options)
  • Mast (size of your choice - choose between aluminium / carbon construction)
  • Mast Foot
  • Base plate (contact us for tuttle option)
  • Bolt set & tools (complete)



NOTE: For individual Foil Components purchase: see tab "FOIL COMPONENTS" on home page


FRONT WINGS:

Foiling has unleashed a fantastic riding potential in light wind but it has also proven to be a fanstastic support to carve some lines on flat water or small waves alike. Imagine a foil that is stable and lifts you at low speed so you can succeed all your transitions or tricks, a foil that glides and can accelerate so you can race you mates for short moment, before you bank on a nice wave to lay a perfect turn. This foil is the Mirage foil.


Built using the Monobloc construction with pre-preg carbon, those foils are both very light and really strong. This set-up offers better load transmission and better stiffness throughout the different parts for maximum control. The Titan connection allows to plug both an aluminium or carbon mast and the fuselage is split in two parts to facilitate transportation.


The Mirage wings are recommended with the C220 Surf stab. This stabilizer offers fantastic glide and great carving potential. Fast and agile it will serve perfectly the Mirage wings with effortless turns and thrilling accelerations.


Front Wing Options:

  • 800 cm2 – the most versatile size of the range offers good lift, good glide and super smooth manoeuvrability.
  • 1,000 cm2 – the largest model offers absolute speed control, early lift and is great at low speed transitions. Can also be used on Surf or SUP foils when riding regular waves


CARBON FUSELAGE TAIL (MIRAGE)

  • Stiff connection
  • Ultralight carbon construction
  • Weight : 0.2 kg


REAR WING - STABC300

Versatile and progressive, the C300 stabilizer can be combined with any front wings and fits a very large range of practices. Equipped with generous winglets, the stabilizer blade offers fantastic control with enough surface area to provide full confidence in all situations. Built in Carbon Composite and designed to be securely mounted on F-ONE fuselages, its profile and angle of incidence were tuned to achieve a very intuitive balance which will help you get your foiling maneuvers in more easily.


OVERVIEW:

  • Early lift and great stability
  • Perfect control at all time
  • Works for Kite, SUP, and Wind Foiling!


Alternative options are available (contact us to arrange):

  • Stab300 Surf
  • Stab275 Surf
  • Stab220 Surf


MAST (ALUMINIUM OPTION)

The F-ONE aluminium mast can be used for all disciplines, kite, surf, stand up paddle and windsurf. The profile is extruded with precision from 6063 aluminium block. The shape of its section benefits from our years of experience in kitefoiling to provide the best gliding feel while keeping the strength up and the weight down. It comes with two stainless steel helicoil inserts at the bottom and at the top to fasten the connecting parts and is therefore fully modular.


The aluminium mast can be used on every foil of the range and it is very easy to jump from one length to another.  A number of parts are available for board connection (Plate, KF, Deep KF, Tuttle).


SIZES: 45cm, 55cm, 65cm, 75cm, 85cm, 95cm


MAST (CARBON OPTION)


A true masterpiece of composite craftmanship and design, the F-ONE Carbon Mast was designed to transform your foiling experience by a significant improvement of the glide and a dramatic weight reduction matched with impressive rigidity.


The design target was to enhance the thrills of foiling, and we believe foiling is always better when your foil glides better, when your foil is easier to drive and when it reacts better to your demands, even at the highest speeds. This is what you will experience when using the F-ONE carbon mast on your existing F-ONE foil or on a new one.


Available in 75 cm, 85 cm and 105 cm, the F-ONE Carbon Mast is ready for all disciplines: surf, wing, kite, SUP. It features a 4-bolt plate at the top (hole spacing: 160×90mm) and an integrated Titan mast foot at the bottom. It can be connected to virtually all boards on the market featuring the twin track system and can receive all the wings and fuselage that feature the TITAN connection slot.


All components are molded together or bonded in factory to ensure the best rigidity throughout. The mast, therefore, comes as a one-piece object, built-in carbon pre-preg with a hollow structure which is molded and cured in one-shot. The numerous layers of carbon are laminated one by one to our exacting demands regarding fiber weight and orientation to achieve the rigidity needed, both in bending and torsion, to keep full control in all situations and at high speeds.


A carbon mast is a superior bit of kit. We think it needs to look great and deliver a superior and flawless behavior on the water. This is what we’ve achieved with the F-ONE Carbon Mast.


SIZES: 75cm, 85cm, 105cm





Advice: Our team are passionate, experienced boardriders. We have a wealth of knowledge and expertise to share and we encourage you to ask for our advice and guidance.


Delivery: We offer discounted shipping to New Zealand (North and South Island). Quotes provided at checkout.


Returns: Our mission is to ensure you are supplied with products that are suitable for their intended purpose. We will always do our best to accommodate genuine returns / exchanges, please see our Terms and Conditions for more information.



SKU: 30344 TAG: Foiling | Kite
