AXIS 2022 Froth

Axis

$2,296.00

or 6 weekly payments from $382.67 Group Created with Sketch. learn more

Size


Designed for SUP Foiling, winging / wingdinging / wing surfing or Downwind. This is a technical shape with the latest concepts for performance riding.

A DESIGN EVOLUTION:

AXIS froth is famous for its perfect balance between performance, early lift and ease
of ride – a stable platform that packs plenty of volume into a short length to reduce swing weight and increase your fun while sup or wingfoiling.

Our newest froth retains this personality, but we’ve made some important design changes
– reflecting the movement towards higher aspect, lower drag foil designs that require more speed to lift-off.

First off, we’ve eliminated the angled cut-away on the tail. This increases the length of the planing surface to increase subfoiling speed potential.

We’ve also reduced the rail bevel – in fact it now fades out completely at the tail adding more width to the planing surface and straightening the water flow for even faster acceleration up to foiling speed.

Also noticeable is the pulled in nose with rounded outline, to reduce the chances of catching in rougher water, compared to the more square nose from 2021.

We’ve increased the thickness and volume up here too, to maintain a balance in
buoyancy that will give you stability when on your knees or stepping up to get going.
A new deck concave gives your feet and toes improved leverage when initiating turns, while feeling safe and secure in a straight line when riding without straps.

Our unique tail pad design ensures any water captured in the concave, flows freely out the back.

We’ve made this season’s Froth and Pump models even tougher, while significantly increasing the stiffness to help transfer every ounce of your pumping energy into the mast and foil.  Full carbon layers top and bottom add further strength and rigidity to a tough PVC foam sandwich top and bottom. A super high-density foam block encases the mast track from the bottom to the deck, further supported with additional carbon layers.

HOW TO SIZE:

Unique to AXIS is the large range of sizes that will ensure you can achieve the volume that’s right for you.

For wingers starting out, we recommend 20-40 litres more than your body weight in kilograms.

Intermediate riders should drop down to roughly the same litres as their body weight (or 10-15 litres above)

Advanced riders can go as small as you dare – the only limit is your athleticism and the steadiness of the wind conditions. If it’s gusty, stay closer to your body weight in litres. SUP foilers will naturally gravitate to the largest sizes in the range.

SIZES // PRICED FROM:

  • 6'8" x 32" 160L // $2,487
  • 6'4" x 31" 145L // $2,455
  • 5'11" x 30" 135L // $2,422
  • 5'8" x 29" 120L // $2,395
  • 5'6" x 28" 110L // $2,378
  • 5'4" x 27" 105L // $2,367
  • 5'2" x 26" 95L // $2,340
  • 5'1" x 25.5" 90L // $2,340
  • 5'0" x 25" 85L // $2,340
  • 4'10" x 24" 75L // $2,323
  • 4'8" x 23.5" 65L // $2,296
  • 4'6" x 23" 55L // $2,269
  • 4'4" x 22" 45L // $2,242


Note: Footstrap inserts are included on all boards except 6'4'' and 6'8'' models.


Froth 160 (6’8” x 32” 160L)
The Froth 160 is our largest and highest volume Froth suited to heavier learners getting into SUP and Wing foiling, offering the most stable platform for progression. Also well suited to school environments. Match this with the BSC 1120 and freeride 500/90 for the ultimate easy up and go solution.

Froth 145 (6’4” x 31” 145L)

The Froth 145 is a higher volume Froth suited to heavier riders and novices getting into SUP and Wing foiling, offering the very stable platform for progression. Also well suited to school environments. Match this with the BSC 1120 or 1060 and freeride 500/90 or 440/90 for the ultimate easy up and go solution.

Froth 135 (5’11” x 30” (135L)
The Froth 135 is a high volume Froth suited to large riders and average sized novices getting into SUP and Wing foiling, offering a very stable platform for progression. Match this with the BSC 1060 and freeride 440/90 for the ultimate easy up and go solution.

Froth 120 (5’8” x 29” 120L)
The Froth 120 is a high volume Froth suited to large riders and average sized novices getting into SUP and Wing foiling, offering a very stable platform for progression. Match this with the BSC 1060 and freeride 440/90 for the ultimate easy up and go solution.

Froth 110 (5’6” x 28” 110L)
The Froth 110 is a moderate volume Froth suited to large/medium weight riders (in gusty areas) and smaller sized novices getting into SUP and Wing foiling, offering a stable platform for progression and rapid advancement. Match this with the BSC 1060 or 970 and freeride 440/90 or 400/90 for the ultimate skill accelerator.

Froth 105  (5’4” x 27” 105L)
The Froth 105 is a moderate volume Froth suited to large/medium weight riders (in gusty areas or as a light wind quiver addition) and light novices getting into Wing foiling, offering a stable platform for progression and rapid advancement. Match this with any of our many front wing/rear wing combination for the ultimate skill accelerator.

Froth 95  (5’2” x 26.5” 95L)
The Froth 95 is a mid volume Froth suited to large/medium intermediate weight riders (in gusty areas), offering a stable platform for progression and rapid advancement. Match this with any of our many front wing/rear wing combination for the ultimate skill accelerator.

Froth 90  (5’1” x 26” 90L)
The Froth 90 is a mid volume Froth suited to medium weight intermediate and advanced riders, offering a versatile platform for progression and rapid advancement. Match this with any of our many front wing/rear wing combination for the ultimate skill accelerator.

Froth 85  (5’0” x 25.5” 85L)
The Froth 85 is a mid volume Froth suited to medium weight intermediate and advanced riders, offering a versatile platform for progression and rapid advancement. Match this with any of our many performance front wing/rear wing combination for the ultimate skill accelerator.

Froth 75  (4’10” x 25” 75L)
The Froth 75 is a mid/lower volume Froth suited to medium weight advanced riders and heavier experts for wingfoiling, prone foiling and tow foiling, offering a versatile platform for progression and rapid advancement. Match this with any of our many high performance front wing/rear wing combination for the ultimate skill accelerator.

Froth 65  (4’8” x 24.5” 65L)
The Froth 65 is a mid/lower volume Froth suited to medium weight advanced to expert riders for wingfoiling, prone foiling and tow foiling, offering a versatile platform for progression and rapid advancement. Match this with any of our many performance front wing/rear wing combination for the ultimate skill accelerator. An excellent flat water pump board

Froth 55  (4’6” x 24” 75L)
The Froth 55 is a mid/lower volume Froth suited to lighter weight advanced to expert riders for wingfoiling, prone foiling and tow foiling, offering a versatile platform for progression and rapid advancement. Match this with any of our many performance front wing/rear wing combination for the ultimate skill accelerator.  An excellent flat water pump board

Froth 45  (4’4” x 23” 75L)
The Froth 45 is a mid/lower volume Froth suited to light weight advanced to expert riders for wingfoiling, prone foiling and tow foiling, offering a versatile platform for progression and rapid advancement. Match this with any of our many performance front wing/rear wing combination for the ultimate skill accelerator. An excellent flat water pump board



Advice: Our team are passionate, experienced boardriders. We have a wealth of knowledge and expertise to share and we encourage you to ask for our advice and guidance.

Delivery: We offer discounted shipping to New Zealand (North and South Island). Quotes provided at checkout.

Returns: Our mission is to ensure you are supplied with products that are suitable for their intended purpose. We will always do our best to accommodate genuine returns / exchanges, please see our Terms and Conditions for more information.


SKU: 30426 TAGS: Foiling | SUP, Foiling | Tow / Wake, Foiling | Wing
